    Contamination Free PP FDA 154gpm High Flow Filter Cartridge

    Ask Lasest Price
    Brand Name : PULLNER
    Model Number : PHBG
    Certification : FDA
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram, Paypal
    Supply Ability : 1000pcs per week
    Delivery Time : 7 days
    • Product Details
    • Company Profile

    Contamination Free PP FDA 154gpm High Flow Filter Cartridge

    35m³/Hr 5 Micron Size 1 Size 2 Bag Filter Replacement High Flow Cartridge Filter

    General information
    PLBG series bag filter pleated high flow filter cartridge is designed to replace Size 1 and Size 2 bag filters. PP pleated type provides a cost-effective alternative with higher removal efficiencies over standard bag media configurations. It’s suitable for existing bag filter vessels, no need add any hardware change. Long service life, save filtration cost.


    Material Construction

    Filter MediaDepth Polypropylene (PP)
    Support/DrainagePolypropylene (PP)
    Cage/Core/End CapGlass Fiber reinforced Polypropylene (PP)

    Performance

    Filtration Micron1μm, 2μm, 5μm, 10μm, 20μm, 40μm, 70μm, 90μm,
    Maximum Operating Differential Pressure3.5bar / 21°C(Inside to Outside)
    Recommend Change-out Differential Pressure1.0 bar / 21°C(Inside to Outside)
    Hot Water Sterilization77-82℃/30min,
    Maximum Operating Temperature82°C

    Flow Rate and Filtration Area

    Size

    Design Flow Rate

    (m3/hr)

    Max Flow Rate

    (m3/hr)

    Filtration Area

    (m2)

    1#10251.6
    2#20503.4

    Ordering Information

    PLBG 0100 01 E

    SeriesMicronLengthSeal Material
    0100=1.0μm2000=20μm01(1#)=330mmE=EPDM
    PLBG0300=3.0μm4000=40μm02(2#)=660mmS=Silicone
    0500=5.0μm7000=70μmCustomizationV=Viton
    1000=10μm9000=90μm
