    RO Pre Filtration PHFM 6.6㎡ High Flow Filter Cartridge

    Ask Lasest Price
    Brand Name : PULLNER
    Model Number : PHFM
    Certification : FDA
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram, Paypal
    Supply Ability : 1500pcs per week
    Delivery Time : 3-7days
    MOQ : 1 piece
    • Product Details
    • Company Profile

    RO Pre Filtration PHFM 6.6㎡ High Flow Filter Cartridge

    Top Selling Products In Google High Flow Filter Cartridge


    Performance Specifications


    Dimensions

    Diameter

    6.5" (160mm)


    Length

    20" (508mm)

    40" (1016mm)

    60" (1524mm)


    Material of Construction:

    Model

    Filter Medium

    Support/Drainage

    End Caps

    Seals Material

    PP

    Deep pleated Polypropylene

    Polypropylene

    Glass Fiber Reinforced Polypropylene

    NBR, Silicone, EPDM, Viton

    PET

    Polyester

    Polyester

    Glass Fiber Reinforced Polypropylene


    Filter Performance

    Micron

    1um, 3um, 5um, 10um, 15um, 20um, 50um, 70um, 100um

    Max. operating temperature

    82℃

    Max. operating differential pressure

    3.44bar@82℃

    Suggestion pressure for filter replacement

    2.5Bar@20℃

    Max. flow rate

    20": 35m3/h

    40": 70 m3/h

    60": 110 m3/h


    General Description

    PHFM series high flow filter cartridge is made of diameter 6.5" and PP pleated design with big flow area and dirt holding capacity. All connection use thermal welding. It can meet different flow requirements, with a wide range of chemical compatibility, can be applied to various fields.


    Application:

    RO pre-filtration, desalination pretreatment;

    Power plant condensation water filtration;

    Biopharmaceutical industry pharmaceutical raw materials, solvents, water filtration;

    Food and Beverage process water treatment;
