Pullner Replacement 5 micron PP Pleated Filter Cartridge For Sea
Water Desalination
PHFL series PP Pleated Filter Cartridge is made of diameter
6"(152mm), single open end, without inner core, pleated type with
inside to outside flow direction. All connection use thermal
welding. Large diameter, big filtration area provide high flow
rate, highly efficient particle filtration in RO pre-filtration
system. Widely used in seawater desalination and power plant
condensate polishing water RO pre-filtration.
Performance Specifications
Dimensions(nominal)
| OD | 6'' (152mm) |
| Length | 20"(508mm), 40"(1016mm), 60"(1524mm) |
Material of Construction:
| Model | Filter Media | Support/Drainage | End Caps | Seals Material |
| PP | Pleated depth | Polypropylene | Glass Fiber Reinforced Polypropylene |
NBR, Silicone, EPDM, Viton
|
| PP | Melt blown | / | Glass Fiber Reinforced Polypropylene |
Filter Performance:
| Micron | 1μm, 5μm, 10μm, 15μm , 20μm, 40μm, 70μm |
| Maximum operating temperature: | 82℃ |
Maximum operating differential pressure
(Inside to outside flow direction) | 3.44bar@82℃ |
| Suggestion pressure for filter replacement | 2.5Bar@20℃ |
| Max. flow rate | 40": 70m3/h |
| 60": 110m3/h |
| Filtration direction | Inside to outside |
Products Details
Operating Demonstration
It easy to operating, all you need to do just to put the filter in
the strainer.
High Flow Filter Cartridge Application:
1.Pharmaceutical industry: Pre-filtration of drugs, distilled
water, biological products, various antibiotics, etc.
2.Electronics industry: Filtration of industrial water such as
electronics, microelectronics, and semiconductors.
3. Food and beverage: Beer, wine, soft drinks, dairy products,
bottled water, fruit wine, juice, syrup, cooking oil, etc
4. Industrial filtration: Energy, coatings, graphite,
petrochemical, electroplating, mining, machining, industrial water
treatment.
5. Water treatment: Drinking water, commercial water treatment,
desalination.
High Flow Filter Cartridge Features and Benefits:
* 40” outer cage is one piece, with high strength can withstand one
adult weight, ensure big effective filtration area, long life;
* Inside to outside flow direction keeps all of the contamination
catched;
* Gradient aperture deep polypropylene fiber filter media, aperture
along the fluid motion direction becomes smaller, levels intercept
different sizes particles, which has excellent dirt holding
capacity and low flow resistance.
* Easy installation save, less cartridge change out help customers
save the labor cost;
* Integral support, high strength, high dirt holding capacity, long
service life;
* Single cartridge could achieve flow rate 110m3/h;
* Filtration systems are 50% smaller than typical size system;
* Filtration efficiency reach 99.8%;
* Strict quality control system, complete production process flow;
* Flexible payment method: T/T, L/C, West Union, Paypal;
* FREE sample.
Application:
1. Water treatment: Drinking water, commercial water treatment,
desalination.
2. Food and beverage: Beer, wine, soft drinks, dairy products,
bottled water, fruit wine, juice, syrup, cooking oil, etc
3. Industrial filtration: Power plant, Energy, coatings, graphite,
petrochemical, electroplating, mining, machining, industrial water
treatment.
Features and Benefits:
* 40'' outer cage is one piece, with high strength can withstand
one adult weight, ensure big effective filtration area, long life;
* Inside to outside flow direction keeps all of the contamination
catched;
* Gradient aperture deep polypropylene fiber filter media, aperture
along the fluid motion direction becomes smaller, levels intercept
different sizes particles, which has excellent dirt holding
capacity and low flow resistance.
* Easy installation save, less cartridge change out help customers
save the labor cost;
* Integral support, high strength, high dirt holding capacity, long
service life;
* Single cartridge could achieve flow rate 110m3/h;
* Filtration systems are 50% smaller than typical size system;
* Filtration efficiency reach 99.8%;
* Strict quality control system, complete production process flow;
* Flexible payment method: T/T, L/C, West Union, Paypal;
* FREE sample.
1. Are you manufacturer or trading company?
We are manufacturer with 7500M2 factory passed ISO9001, ISO14001,
ISO45001 management certification.
2. What's about the MOQ?
Small MOQ for customers, can be negotiated according to customers’
requirements.
3. What's about the sample cost?
We provide free sample, you just need to pay for the freight.
4. How about the delivery?
The goods will be sent out in 7 working days after pre-payment.
5. How is the feedback from customer?
Our high quality products and professional service have won the
recognition of customers, get their good feedback and next purchase
orders.
